beijing sanhe science&technology co., ltd
9 Years
| Ask Lasest Price | |
| Brand Name : | kaixin |
| Model Number : | LM-F20 |
| Certification : | UL CE ROHS ISO ETL SGS SAA Fcc EMC |
| Price : | Negotiation |
| Payment Terms : | Western Union, MoneyGram, T/T VISA |
| Supply Ability : | 5,000 square meters per month |
Scoreboard LED Display Project for Football Stadium Perimeter P10 / P16 / P20 Outside
Features:
1. High brightness. Use DIP LEDs, keeps the display content visible
even if facing the strong sunshine directly.
2. With Anti-UV ray mask, the color of the mask would never change
even if under exposure of UV ray.
3. Waterproof design, completely outdoor use.
4. Easy for assembling and connection with the connector added.
5. High color uniformity and clear image can bring you a vivid
audio visual effect.
6. Both front and rear access are available.
7. Good LED Chips, with large viewing angle, lowe power consumption
and good color uniformity.
8. Easy for maintenance.
9. Good quality raw material, accurate technique and careful
inspection insures the high quality of led display.
10. Different shape and size can be made according to your
requirement.
11. Widely used for building, shopping mall, cinema, station,
stadium, plaza, street etc.
Stadium perimeter led display screen Specifications:
| Module:LM-F20 | LED Type | DIP546 | |
| Pixel Pitch | 20mm | Refresh frequency | 3,000Hz |
| Module Size | 320x160mm, 320mmx320mm | View Angle | 120 0/900 |
| Module resolution | 16x8pixel, 16x16pixel | Working Environment | Temp:-20°C~60°C, Humidity:10%~90% |
| Dot density | 2,500pixel/sq. m | Working Voltage | AC:100V~120V AC:220~240V |
| Pixel configuration | 2R1G1B | Lifetime | 100,000Hours |
| The best view distance | >18m | Gray Scale | 14bit/color |
| Cabinet dimension | 1280mmx960mm(Optional) | Color Display | 1.07Billion |
| Cabinet resolution | 64X48 | Brightness | ≥6500nit |
| Cabinet weight | 58KG/sq. m | MITBF | 0.00001 |
| Drive mode | Constant current,Static Scan | IP | IP65 |
| Max Power Consumption | 850W/sq. m | Warranty | 2-5 years |
| LED Parameter | R:d(625-630nm) R:IV(400-450mcd) | G:d(522.5-525nm) G:IV(1800-2200mcd) | B:d(467.5-470nm) B:IV(350-400mcd) |
| Image adjustment | Brightness, contrast, tone, color range etc | ||
| Brightness uniformity | Ratio of min pixel brightness /max pixel<0.9(When each color reaches its highest brightness) | ||
| Effective control distance | Cat 5<100M / Multi-mode fiber:<500M / Single-mode fiber<20Km | ||
| Color Temperature/contrast | Brightness and contrast of red, green and blue can be adjusted by software,100 scales are available, color temperature is adjustable | ||
| Input signal | RF,S-VIDEO,RGB,RGBTV,YUT,YC,COMPISITION | ||
| Control system | Sending card+Receiving card+Hub card+DVI Card+PCTV Non-liner card+Muti-funcational card(Optional)+Video processor(Optional)+ Fiber Transmitter(Optional) | ||
