IP65 High Brightness SMD 3 in 1 Outdoor Rental LED Display DIP P8 RGB 3535
Product Description
1. SMD 3-in-1 technology and quality LED chip is used for indoor
LED Display
2. Wide view angle: 140 in horizontal and 140 in vertical.
3. Special design and advanced SMT technology improves the heat
dissipation.
4. With high refresh rate controller, guarantee that no scan line
when taking photos and a truly color display
5. High color uniformity and clear image can bring you a vivid
audio visual effect.
6. Humanized design cabinet, super slim & light weight. Fast
assemble and disassemble
Product Parameter:
| Pixel pitch | 5mm | Module size | 160 x 160mm |
| Pixel configuration | 1R1G1B | Module Resolution | 32 x32dots |
| View angel | 140°/140° | Pixel density | 40,000dots/sqm |
| LED encapsulation | SMD3528 | Refresh Rate | ≥1000Hz |
| Cabinet size | Normal 640x640 | Cabinet material | Aluminum alloy |
| Designed by requirements | Die-casting aluminum | ||
| Cabinet thickness | < 8cm or | Cabinet weight | < 10kg/cabinet or |
| Designed by requirements | Designed by require | ||
| Driving Method | 1/8 scan, constant current | Max power consumption | 700w/sqm |
| Brightness | ≥2000nits | Average Power consumption | 350 w/sqm |
| Working voltage | AC110 / 230V ±15% | Working temp | -20℃to +60℃ |
| Best viewing distance | >4 m | Working humidity | 35%~85% |
| LED parameters | R: 620 - 625nm | MTBF | >5,000hours |
| IV:250- 300mcd | |||
| G:520 - 523nm; | Gray Level | RGB/65536/16bit | |
| IV:800 - 1000mcd | |||
| B: 467 - 470nm; | Lifespan | >100,000hours | |
| IV:200 - 230mcd | |||
| Image processing | Video denoising, rapid motion compensation, edge sharpening, edge smoothing, | ||
| color coordinate conversation&control , grey scale transformation etc | |||
| Brightness uniformity | Ratio of min pixel brightness /max pixel<0.9 | ||
| Control distance | Cat-5<100M,Multi-mode fiber:<500M;Single-mode fiber<20Km | ||
| Color Temperature | Brightness and contrast of red, green and blue can be adjusted by software, | ||
| 100 scales are available, color temperature is adjustable | |||
| Input signal | RF,S-VIDEO,RGB,RGBTV,YUT,YC,COMPISITION | ||
| Control system | Sending card+Receiving card+Hub card+DVI Card+PCTV Non-liner card+Muti-funcational card(Optional)+Video processor(Optional)+ Fiber Transmitter(Optional) | ||
