1R1G1B SMD LED Display P8 , Stage Background Full Color LED Curtain Wall
Product Features:
The pixel matrix features a unique clear lens covering which offers
superior range of viewing angle,contrast,and angle.
Outdoor versions of the Video Max are designed to withstand harsh
environmental conditions,such as sun glare,heat,cold,
and humidity. Leeman full color LED display is popular for
advertising applications.
1. indoor P3, P4, P5, P6, P7.62, P8, P10, P12
2. outdoor P6, P6.25, P6.94, P7.62, P8.928, P10, P12, P12.5, P14,
P16, P20, P25 ,P31.25, P45
1. Stable performance, wide applicability, high brightness, high
protection grade.
2. high temperature resistant and aging resistant PC materials are
applied in the modules to get rid of the mosaic problem even after
long time use.
3. High brightness enables longer viewing distance and ensures the
spectators far from the screen can still enjoy what is shown, even
under direct sunlight.
4. The cabinets, featuring great moisture and corrosion proofing,
enable themselves to work in all weather conditions.
Technical Parameters:
| Specification | PH8 | PH10 |
| Pixel Configuration | 1R1G1B | 1R1G1B |
| Density of pixel | 1/4 scan | 1/4 scan |
| Module Resolution | 32*16(W*H) | 16*16(W*H) |
| Pixel density | 15625 | 10000 |
| Pixel Pitch | 8mm | 10mm |
| Best Viewing Distance | 6~12m | 8~15m |
| Module Size(mm) | 320*160 | 160*160 |
| Cabinet Size(mm) | 960*960 | 960*960 |
| Weight | 55Kg | 55Kg |
| Working Voltage | AC220/110 ± 10%, 47~63Hz | |
| Waterproof Rate | IP65 | |
| Maxim Power | ≤780W | |
| Average Power | ≤450W | |
| Viewing Angle | Horizontal:≥ 120° Vertical:≥60° | |
| Brightness | ≥8000 nits | |
| Working Temperature | -20ºC to +60ºC | |
| Operating humidity | 20% to 90% | |
| Lifespan (50% Brightness) | 100,000 hours | |
1. Wide application field & short ROI time:
commercial advertising LED display screen, Stadium perimeter LED
display screen, Mobile trailer LED display screen for mobile media,
shopping mall LED display screen for logo showing, bank stock
exchange LED display screen for rates showing, train & bus station
LED display screen, air port LED display screen, telecommunication
LED display screen system for information showing and instruction
2. High Contrast ratio: 4000:1
Which is a very high level to ensure a vivid image of our LED
display screen system.
3. First-class LED chip:
Supplied by Nichia of Japan & other high strictly selected LED chip
to ensure the long lifetime and high brightness of our LED display
screen system
4. Easy Installation & Using:
easy & simple installation interface and user friendly software to
ensure the user friendly interface of the LED display screen system
5. Convenient Servicing:
Front and rear cabinet access makes the maintenance work very
convenient and low cost to help you concentrate more time and
energy on your main marketing promotion business.
