Store / Jewelry Exhibition Hall P10 LED Screen for Transparent Video Advertising
Description:
1. Good visualization
Glassbased design allows the light to pass through the glass
without any influence to the building
structure around.Transparency of the glass screen can up to 85%.
2. Ultra-thin, and ultra-light.
The thick can up to 1cm, and the weight can up to 7kg/m2
High brightness, and high definition.
The brightness can up to 8500 cd/m2.
4. Easy and convenient maintenance.
It can be maintained from inside, safer and more convenient.
5. Saving lighting costs of the whole building.
Besides good advertising effect, LED glass display also helps
lighting the glass wall, thus makes the glass
wall more attractive and saving a lot lighting cost.
6. Wide use range.
Wherever the glass wall is, glass LED display can be installed.
Such as bank, supermarket, theater,
business street, hotel, public civic buildings, and landmark buildings, etc.
Technological Parameters:
| Category | Parameter |
| Pixel Pitch | 10mm |
| Optimum Viewing Distance | 10-25m |
| Density of Pixel | 10000pixels/m2 |
| Brightness | ≥5000cd/m2 |
| Module Resolution | 64dots*32dots |
| LED Encapsulation | SMD3528 1R1G1B |
| Driving Method | Real Static |
| Optimum Viewing Angle | H120°V100° |
| Cabinet Size | 640*640*10(mm) |
| Max Power Consumption | 1100w/m2 |
| Cabinet Weight | 15kg/m2 |
| Light Transmittance | ≥75% |
| IP Rating | Front/Rear IP20 |
| Refresh Rate | 1400Hz |
| Color Depth | 16bit |
| Luminance Consumption | Less than 5% after 1000 hours Ageing test |
| MTBF | 5000hours |
| Defective Dot Rate | 0.0001 |
| Life Span | 100000hours |
| Working Voltage | 110-240 AC±10% 50-60Hz |
| Working Temperature/Humidity | -30°C - +45°C/10-90%RH |
| Storage Temperature/Humidity | -20°C - +60°C/10- 90%RH |
| Input Signal | RF,S-VIDEO,RGBHV,YUV,YC & COMPOSITION,etc |
Application:
Applicable in all buildings decorated with glasses such as banks,
shopping malls, theatres, business streets, chain stores, hotels,
municipal administration buildings, landmark architectures.
Warranty:
1. If the area is larger, we usually require customers or dealers
to send someone to come to factory to study, training time a week,
the main study screen operation, maintenance. Company training and
providing accommodation are free of charge.
2. If the area is in more than 20 square meters of outdoor full
color, it must have all accessories.
3. Response within 2 hours, non-artificial, general fault solution
within 24 hours, and acceptable failure resolved within 48 hours.
