P16 High Transparent LED Display , Outdoor Video Glass Wall working Temperature -10~40℃
Main Characteristics:
1. Good visualization:
Glass based design allows the light to pass through the glass
without any influence to the building structure around..
2. Ultra-thin, and ultra-light.
With only 8mm width and 12kg/m2 weight, the installed glass display takes very little space and without any increase in the glass wall loading weight.
3. Frameless structure
Leeman glass display can directly stick to the inside part of the glass wall by special designed glue, and after 10 seconds curing, it will connect with the glass wall firmly. Thus decrease the installation difficulty and cost greatly.
4. Easy and convenient maintenance.
It can be maintained from inside, safer and more convenient.
5. Saving lighting costs of the whole building.
Besides good advertising effect, Leeman LED glass display also helps lighting the glass wall, thus makes the glass wall more attractive and saving a lot lighting cost.
6. Wide use range.
Wherever the glass wall is, Leeman glass LED display can be installed. Such as bank, supermarket, theater, business street, hotel, public civic buildings, and landmark buildings, etc.
Technology Parameter:
| Pixel pitch | 10mm | 16mm | 20mm |
| LED lamp | SMD3528 | SMD5050 | SMD5050 |
| Module size(mm) | 320 x 320 | 512 x 256 | 640 x 320 |
| Module resolution | 32 x 32 | 32 x 16 | 32 x 16 |
| Brightness (CD/sqm) | 4200 | 3500 | 3000 |
| See-through area | ≥75% | ≥70% | ≥75% |
| Maximum power consumption (W/sqm) | 1200 | 950 | 680 |
| Average power consumption(W/sqm) | 420 | 330 | 240 |
| Viewing angle (50% brightness) | Horizontal:140°(+70°/-70°);Vertical:140°(+70°/-70°) | ||
| Processing depth | 16bit | ||
| Video frame rate | 60 frame/Sec. | ||
| Display refresh rate | 2000 Hz (MBI5024,) | ||
| Thickness | 10mm | ||
| Ingress protection | IP20 | ||
| Controller | LINSN | ||
| Video input | VGA mapped / NTSC / PAL,JPG,BMP,AVI,WMV,RM etc. | ||
| Video display function | text, graphics, pictures, signs, flashes | ||
| Operating Temperature range | —10℃~+45℃ | ||
| Operating Humidity range | 10%—95%RH | ||
| Screen Weight | 13--15kg/sqm | ||
* High Degree of Visibility
80% transparent see-through, so it is convenient for people inside
and outside to look-through. The integrated LED lamps are very tiny
and almost invisible from outside of the building.
* Compact Design and Light Weight
8mm thickness of the LED panel has it almost suitable for any glass
wall building.The weight is only 12 kg/sqm and minimizes the load
to the glass wall.
* Ease of the Installation and Maintenance
No need to change any building structure. The modules can be stuck
to the back of the glass wall by the special glue which presented
by us. It needs only 10 second to install one module. Should any
maintenance occurs, it only requires to do it at the indoor.
* Saving Money in Decoration for the Architecture
Since the LED glass wall makes the vivid decoration and
advertising, it saves other lights to lighting up the building.
* Wide Application
The Glass Wall LED Screen can be applied wherever the glass wall
existed such as commercial building,landmark,architecture, art
center,shopping mall, super market, shain stores etc.
