P10 / 12 Clear Transparent Glass Advertising LED Display for Shopping Mall Facade
Indoor Glass led screen is very popular in our company at present.P10.416mm/P12.5mm indoor high brightness glass led screen with high transparency and low self-weight. Please kindly check the photos,The wire lines and power supply were be hidden in it,Greatly increase glass screen transparency. Besides,Our engineer design the hook,made it easy to install and replace. Two panel sizes for optional. One is 500*500mm ,the other is 500*1000mm.The Maximum thickness is 54mm,what's more,The thickness included power supply & receiving card.
1. Standard Module Size
Standard size can be used to assemble larger DispLays, using The
right resolution for The job.
2. Quick & Easy installation
Only hand assembly required. Modules easily snap together with
support frames.
Leeman’s transparent X-Glass displays are modular and snap into
place on support frames. At a maximum size of 960mm x 320mm
approximately 3.15’ W x 1.05’ H), the modules can be hand assembled
with fewer vertical bars when creating larger, more powerful
displays (as shown above).
3. best seLLing product model with high brightness and resolution,
highly customizabLe.
Specification:
| Pixel Pitch | 10mm |
| Optimum Viewing Distance | 10-25m |
| Density of Pixel | 10000pixels/m2 |
| Brightness | ≥4000cd/m2 |
| Module Resolution | 64dots*32dots |
| LED Encapsulation | SMD3528 1R1G1B |
| Driving Method | Real Static |
| Optimum Viewing Angle | H120°V100° |
| Cabinet Size | 640*640*10(mm) |
| Max Power Consumption | 1100w/m2 |
| Cabinet Weight | 15kg/m2 |
| Light Transmittance | ≥75% |
| IP Rating | Front/Rear IP20 |
| Refresh Rate | 1400Hz |
| Color Depth | 16bit |
| Luminance Consumption | Less than 5% after 1000 hours Ageing test, |
| MTBF | 5000hours |
| Defective Dot Rate | 0.0001 |
| Life Span | 100000hours |
| Working Voltage | 110-240 AC±10% 50-60Hz |
| Working Temperature/Humidity | -10°C - +45°C/10-90%RH |
| Storage Temperature/Humidity | -20°C - +60°C/10- 90%RH |
| Input Signal | RF,S-VIDEO,RGBHV,YUV,YC & COMPOSITION,etc |
Features:
1. High transparency
More that 70% transparency, better transmittance. It may satisfy
higher requirement of day-lighting, light transmission. Nearly
imperceptible the LED display from a distance.
2. Slim & Light
22mm thickness, weight 19 kg/sq.m, has little loading demand for
the glass curtain wall
3. Quick & Easy installation
Standard size can be used to assemble larger displays. All power
supplies and receiving cards are build into the modules, and power
cables can easily be connected.
4. High brightness
Brightness can up to 4000 nits, applicable to direct sunshine
environment.
